Product 78RBD23937

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073153623
QR Code
Url
https://catalogonuevo.rbrake.com/Producto/Details?idProducto=78RBD23937
Weight (gr.)
16300
R90 Homologation
R90 90R-02C0452/0127
Measures
Ø300x25x48.5
Brake Disc Type: Vented
Minimum thickness [mm]: 23
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 63.5
Reference applications
Brand OE Reference
FORD 1 223 664
FORD 1 223 666
FORD 1 253 964
FORD 1 253 965
FORD 1 323 560
FORD 1 373 370
FORD 1 469 083
FORD 1 500 152
FORD 1 501 059
FORD 1 520 297
VOLVO 2 745 10
VOLVO 3 126 271 9
Maker Cross reference
ATE 24.0125-0162.1
BENDIX ANTIGUO 562363B
BOSCH 0 986 479 171
BREMBO 09.9468.11
BREMBO 09.C138.1X
DELPHI LOCKHEED BG3895
FERODO DDF1225
LETEC LBF044V
ROAD HOUSE 6711.10
SANLI SL34440
TRW DF4424
FORD
C-MAX (DM2) MPV 02/2007-09/2010
Vehicle Engine Fuel Date CC KW CV Traction
2.0 CNG

SYDA

 16 04/2009-09/2010 1999 107 145 1
2.0 LPG

SYDA

 18 06/2008-09/2010 1999 107 145 1
1.8 TDCi

KKDA

KKDB

 2 02/2007-09/2010 1753 85 115 1
C-MAX II (DXA/CB7, DXA/CEU) MPV 04/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

M2DA

M2DC

 1 10/2012-06/2019 998 74 100 1
1.0 EcoBoost

B7DA

M1DA

M1DD

 1 10/2012-06/2019 998 92 125 1
1.0 EcoBoost 1 07/2018-06/2019 999 74 100 1
1.0 EcoBoost 1 07/2018-06/2019 999 92 125 1
1.5 EcoBoost

M8DB

 1 03/2015-06/2019 1498 110 150 1
1.5 EcoBoost

M9DB

 1 03/2015-06/2019 1498 134 182 1
1.6 EcoBoost

JQDA

JQDB

 1 12/2010-06/2019 1596 110 150 1
1.6 EcoBoost

JTDA

JTDB

 1 12/2010-06/2019 1596 134 182 1
1.6 Ti

XTDA

XTDB

 1 12/2010-06/2019 1596 63 85 1
1.6 Ti

IQDA

IQDB

 1 12/2010-06/2019 1596 77 105 1
1.6 Ti

MUDA

MUDD

 1 02/2012-06/2019 1596 88 120 1
1.6 Ti

PNDA

PNDD

 1 12/2010-06/2019 1596 92 125 1
2.0 Energi

UADA

 13 01/2015-06/2019 1999 136 185 1
1.6 CNG

MUDA

 16 01/2013-12/2014 1596 86 117 1
1.6 LPG

MUDA

MUDD

 18 02/2012-06/2019 1596 86 117 1
1.6 LPG

MUDA

MUDD

 18 02/2012-06/2019 1596 88 120 1
1.6 Flexifuel

MUDA

MUDD

 19 02/2011-06/2019 1596 88 120 1
1.5 TDCi

XXDA

XXDC

XXDD

 2 03/2015-06/2019 1499 70 95 1
1.5 TDCi

XWDA

XWDB

XWDC

XWDD

XWDE

 2 03/2015-06/2019 1499 88 120 1
1.5 TDCi ECOnetic

AEDA

 2 03/2015-06/2019 1499 77 105 1
1.6 TDCi

T3DA

T3DB

 2 12/2010-06/2019 1560 70 95 1
1.6 TDCi

T1DA

T1DB

 2 12/2010-06/2019 1560 85 115 1
2.0 TDCi

TYDA

 2 02/2011-06/2019 1997 85 115 1
2.0 TDCi

UKDB

 2 02/2011-06/2019 1997 100 136 1
2.0 TDCi

UFDB

 2 04/2010-06/2019 1997 103 140 1
2.0 TDCi

T7DB

T7DC

T7DD

 2 03/2015-06/2019 1997 110 150 1
2.0 TDCi

TXDB

 2 12/2010-06/2019 1997 120 163 1
2.0 TDCi

T8DE

 2 03/2015-06/2019 1997 125 170 1
C-MAX II () Box Body/MPV 10/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

M2DA

M2DC

 1 10/2012-06/2019 998 74 100 1
1.0 EcoBoost

B7DA

M1DA

M1DD

 1 10/2012-06/2019 998 92 125 1
1.5 EcoBoost

M8DB

 1 03/2015-06/2019 1498 110 150 1
1.5 EcoBoost

M9DB

 1 03/2015-06/2019 1498 134 182 1
1.6 EcoBoost

JQDA

JQDB

 1 12/2010-06/2019 1596 110 150 1
1.6 EcoBoost 1 12/2010-06/2019 1596 134 182 1
1.6 Ti 1 10/2010-06/2019 1596 77 105 1
1.5 TDCi

XWDA

XWDB

XWDC

XWDD

XWDE

 2 03/2015-06/2019 1499 88 120 1
1.5 TDCi ECOnetic

AEDA

 2 03/2015-06/2019 1499 77 105 1
1.6 TDCi

T3DA

T3DB

 2 12/2010-06/2019 1560 70 95 1
1.6 TDCi

T1DA

T1DB

 2 12/2010-06/2019 1560 85 115 1
2.0 TDCi

TYDA

 2 02/2011-06/2019 1997 85 115 1
2.0 TDCi

UFDB

 2 02/2011-06/2019 1997 103 140 1
2.0 TDCi

T7DB

T7DC

 2 03/2015-06/2019 1997 110 150 1
2.0 TDCi

TXDB

 2 12/2010-06/2019 1997 120 163 1
2.0 TDCi

T8DE

 2 03/2015-06/2019 1997 125 170 1
FOCUS II (DA_, HCP, DP) Hatchback 07/2004-09/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 06/2005-09/2008 1999 104 140 1
2.0 CNG

SYDA

 16 04/2009-07/2011 1999 107 145 1
2.0 LPG

SYDA

 18 06/2008-07/2011 1999 107 145 1
2.0 Flex

SYDA

 19 10/2008-03/2010 1999 107 145 1
2.0 TDCi

G6DE

G6DF

 2 07/2004-01/2008 1997 98 133 1
FOCUS II () Estate Van 07/2004-07/2011
Vehicle Engine Fuel Date CC KW CV Traction
2.0 TDCi

IXDA

 2 06/2009-07/2011 1997 81 110 1
2.0 TDCi

G6DB

 2 09/2005-07/2011 1997 100 136 1
FOCUS II Turnier (DA_, FFS, DS) Estate 07/2004-09/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.0 LPG

SYDA

 18 06/2008-07/2011 1999 107 145 1
2.0 TDCi

G6DE

G6DF

 2 07/2004-01/2008 1997 98 133 1
FOCUS III (C346) Hatchback 07/2010-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 09/2011-06/2018 1999 119 162 1
FOCUS III (C346) Saloon 07/2010-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 08/2011-02/2020 1999 119 162 1
FOCUS C-MAX (DM2) MPV 10/2003-03/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.0

AODA

AODB

AODE

SYDA

 1 03/2004-03/2007 1999 107 145 1
1.8 TDCi

KKDA

KKDB

 2 01/2005-03/2007 1753 85 115 1
2.0 TDCi

G6DC

G6DE

G6DF

 2 10/2003-03/2007 1997 98 133 1
2.0 TDCi

G6DA

G6DB

G6DD

G6DG

 2 10/2003-03/2007 1997 100 136 1
GRAND C-MAX (DXA/CB7, DXA/CEU) MPV 12/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

B3DA

M2DA

M2DC

 1 10/2012-06/2019 998 74 100 1
1.0 EcoBoost

B7DA

M1DA

M1DD

 1 10/2012-06/2019 998 92 125 1
1.0 EcoBoost 1 07/2018-06/2019 999 74 100 1
1.0 EcoBoost 1 07/2018-06/2019 999 92 125 1
1.5 EcoBoost

M8DB

 1 03/2015-06/2019 1498 110 150 1
1.5 EcoBoost

M9DB

 1 03/2015-06/2019 1498 134 182 1
1.6 EcoBoost

JQDA

JQDB

 1 12/2010-06/2019 1596 110 150 1
1.6 EcoBoost

JTDA

JTDB

 1 12/2010-06/2019 1596 134 182 1
1.6 Ti

XTDA

 1 12/2010-06/2019 1596 63 86 1
1.6 Ti

IQDA

IQDB

 1 12/2010-06/2019 1596 77 105 1
1.6 Ti

PNDA

PNDD

 1 12/2010-06/2019 1596 92 125 1
1.5 TDCi

XXDA

XXDC

 2 03/2015-06/2019 1499 70 95 1
1.5 TDCi

XWDA

XWDB

XWDC

XWDD

XWDE

 2 03/2015-06/2019 1499 88 120 1
1.6 TDCi

T3DA

T3DB

 2 12/2010-06/2019 1560 70 95 1
1.6 TDCi

T1DA

T1DB

 2 12/2010-06/2019 1560 85 115 1
2.0 TDCi

TYDA

 2 02/2011-06/2019 1997 85 115 1
2.0 TDCi

UKDB

 2 02/2011-06/2019 1997 100 136 1
2.0 TDCi

UFDB

 2 02/2011-06/2019 1997 103 140 1
2.0 TDCi

T7DB

T7DC

 2 03/2015-06/2019 1997 110 150 1
2.0 TDCi

TXDB

 2 12/2010-06/2019 1997 120 163 1
2.0 TDCi

T8DE

 2 03/2015-06/2019 1997 125 170 1
GRAND C-MAX () Box Body/MPV 12/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

B3DA

M2DA

M2DC

 1 10/2012-06/2018 998 74 100 1
1.0 EcoBoost

B7DA

M1DA

M1DD

 1 10/2012-06/2019 998 92 125 1
1.5 EcoBoost

M8DB

 1 03/2015-06/2019 1498 110 150 1
1.6 EcoBoost

JQDA

JQDB

 1 12/2010-06/2019 1596 110 150 1
1.6 EcoBoost 1 12/2010-06/2019 1596 134 182 1
1.6 Ti 1 12/2010-12/2014 1596 92 125 1
1.5 TDCi

XWDA

XWDB

XWDC

XWDD

XWDE

 2 03/2015-06/2019 1499 88 120 1
1.6 TDCi

T3DA

T3DB

 2 12/2010-06/2019 1560 70 95 1
1.6 TDCi

T1DA

T1DB

 2 12/2010-06/2019 1560 85 115 1
2.0 TDCi

TYDA

 2 02/2011-06/2019 1997 85 115 1
2.0 TDCi

UFDB

 2 12/2010-06/2019 1997 103 140 1
2.0 TDCi

T7DB

T7DC

 2 03/2015-06/2019 1997 110 150 1
2.0 TDCi

TXDB

 2 12/2010-06/2019 1997 120 163 1
2.0 TDCi

T8DE

 2 03/2015-06/2019 1997 125 170 1
KUGA II / ESCAPE III (DM2) SUV 05/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 EcoBoost

BNMA

 1 01/2016-06/2019 1499 88 120 1
1.5 EcoBoost

M8MA

 1 09/2014-06/2019 1499 110 150 1
1.5 EcoBoost 1 10/2015- 1499 132 180 1
1.5 EcoBoost

M9MA

 1 06/2016- 1499 134 182 1
1.6 EcoBoost

JQMA

JQMB

 1 03/2013-09/2014 1596 110 150 1
2.0 1 03/2013-06/2016 1999 179 243 1
2.5 1 01/2014-12/2019 2488 110 150 1
2.5 1 09/2013- 2488 125 170 1
1.5 TDCi

XWMB

XWMC

 2 07/2016-06/2019 1499 88 120 1
2.0 TDCi

TYMA

 2 03/2013-12/2019 1997 85 115 1
2.0 TDCi

XRMA

XRMB

 2 09/2014-06/2019 1997 88 120 1
2.0 TDCi

UKMA

 2 03/2013-12/2019 1997 100 136 1
2.0 TDCi

UFMA

 2 03/2013-09/2014 1997 103 140 1
2.0 TDCi

T7MA

T7MB

T7MC

T7MD

 2 09/2014-06/2019 1997 110 150 1
2.0 TDCi 4x4

TXDA

TXMA

 2 03/2013-09/2014 1997 120 163 3
1.5 EcoBoost E85 31 02/2019-11/2019 1499 110 150 1
KUGA II / ESCAPE III () SUV Van 05/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 EcoBoost

BNMA

 1 06/2019-12/2019 1499 88 120 1
1.5 EcoBoost

M8MA

 1 09/2014-12/2019 1499 110 150 1
1.5 TDCi

XWMB

XWMC

 2 01/2019-12/2019 1499 88 120 1
2.0 TDCi

XRMA

XRMB

 2 06/2019-12/2019 1997 88 120 1
2.0 TDCi 2 06/2012-12/2019 1997 103 140 1
2.0 TDCi

T7MA

T7MB

 2 09/2014-12/2019 1997 110 150 1
TOURNEO CONNECT II / GRAND TOURNEO CONNECT V408 () MPV 09/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

B3GA

M2GA

M2GB

 1 11/2013-12/2022 998 74 100 1
1.6 EcoBoost

JQGA

 1 11/2013-12/2022 1596 110 150 1
1.5 TDCi

XUGA

 2 05/2015-12/2022 1499 55 75 1
1.5 TDCi 2 08/2016-12/2022 1499 70 95 1
1.5 TDCi

XVGA

XVGB

XVGC

XXGA

 2 05/2015-12/2022 1499 74 101 1
1.5 TDCi

XWGA

XWGB

XWGC

 2 05/2015-12/2022 1499 88 120 1
1.6 TDCi

UBGA

 2 09/2013-12/2022 1560 55 75 1
1.6 TDCi

TZGA

TZGB

 2 09/2013-12/2022 1560 70 95 1
1.6 TDCi

T1GA

 2 09/2013-12/2022 1560 85 115 1
TRANSIT CONNECT II () MPV 02/2013-
Vehicle Engine Fuel Date CC KW CV Traction
2.5 Duratec 1 09/2013- 2488 126 171 1
2.5 CNG 16 09/2013- 2488 126 171 1
2.5 LPG 18 09/2013- 2488 126 171 1
1.5 TDCi

XUGA

 2 08/2015- 1499 55 75 1
1.5 TDCi

XVGA

XVGB

XVGC

XXGA

 2 05/2015- 1499 74 101 1
1.5 TDCi

XWGA

XWGB

XWGC

 2 05/2015- 1499 88 120 1
1.6 TDCi

UBGA

 2 02/2013- 1560 55 75 1
1.6 TDCi

TZGA

TZGB

 2 02/2013- 1560 70 95 1
1.6 TDCi

T1GA

 2 02/2013- 1560 85 115 1
TRANSIT CONNECT II V408 () Box Body/MPV 02/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 EcoBoost

B3GA

M2GA

M2GB

 1 02/2013- 998 74 100 1
1.6 EcoBoost

JQGA

 1 11/2013- 1596 110 150 1
2.5 Duratec 1 09/2013- 2488 126 171 1
2.5 CNG 16 09/2013- 2488 126 171 1
2.5 LPG 18 09/2013- 2488 126 171 1
1.5 EcoBlue

Z2GA

 2 05/2018- 1499 74 101 1
1.5 TDCi

XUGA

 2 08/2015- 1499 55 75 1
1.5 TDCi 2 03/2016- 1499 70 95 1
1.5 TDCi

XVGA

XVGB

XVGC

XXGA

 2 05/2015- 1499 74 101 1
1.5 TDCi

XWGA

XWGB

XWGC

 2 05/2015- 1499 88 120 1
1.6 TDCi

UBGA

 2 02/2013- 1560 55 75 1
1.6 TDCi

TZGA

TZGB

 2 02/2013- 1560 70 95 1
1.6 TDCi

T1GA

 2 02/2013- 1560 85 115 1
VOLVO
C30 (533) Hatchback 09/2006-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.4 i

B 5244 S4

 1 10/2006-12/2012 2435 125 170 1
T5

B 5254 T7

 1 03/2007-12/2012 2521 169 230 1
T5 1 10/2007-12/2013 2521 184 250 1
2.0 FlexFuel

B 4204 S4

 19 01/2010-12/2012 1999 107 146 1
2.0 D

D 4204 T

 2 10/2006-12/2012 1998 100 136 1
D5

D 5244 T9

 2 10/2006-12/2012 2400 120 163 1
D5

D 5244 T13

D 5244 T8

 2 10/2006-12/2012 2400 132 180 1
C70 II (542) Convertible 03/2006-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.4

B 5244 S5

 1 03/2006-10/2009 2435 103 140 1
2.4 i

B 5244 S4

 1 03/2006-10/2009 2435 125 170 1
T5

B 5254 T3

 1 03/2006-02/2007 2521 162 220 1
T5

B 5254 T7

 1 03/2007-06/2013 2521 169 230 1
2.0 D

D 4204 T

 2 01/2008-10/2009 1998 100 136 1
2.4 D

D 5244 T9

 2 03/2007-06/2013 2400 120 163 1
S40 II (544) Saloon 12/2003-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.6

B 4164 S3

 1 01/2005-12/2012 1596 74 101 1
1.8

B 4184 S11

 1 04/2004-12/2010 1798 92 125 1
2.0

B 4204 S3

 1 10/2006-12/2012 1999 107 146 1
2.4

B 5244 S5

 1 01/2004-12/2010 2435 103 140 1
2.4

B 5244 S4

 1 01/2004-12/2012 2435 125 170 1
T5

B 5254 T3

 1 01/2004-12/2007 2521 162 220 1
T5

B 5254 T7

 1 03/2007-12/2012 2521 169 230 1
T5 AWD

B 5254 T3

 1 04/2004-12/2007 2521 162 220 3
T5 AWD

B 5254 T7

 1 03/2007-12/2010 2521 169 230 3
1.8 Flexfuel

B 4184 S8

 19 01/2006-12/2010 1798 92 125 1
2.0 F

B 4204 S4

 19 10/2009-12/2012 1999 107 146 1
2.0 CDI

D 4204 T2

 2 07/2005-12/2006 1998 98 133 1
2.0 D

D 4204 T

 2 01/2004-12/2010 1998 100 136 1
2.4 CDI

D 5244 T9

 2 03/2007-12/2010 2400 120 163 1
D2

D 4162 T

 2 10/2010-12/2012 1560 84 115 1
D3

D 5204 T5

 2 10/2010-12/2012 1984 110 150 1
D4

D 5204 T

 2 10/2010-12/2012 1984 130 177 1
D4

D 4204 T2

 2 07/2005-12/2006 1998 96 131 1
D5

D 5244 T13

D 5244 T8

 2 03/2006-12/2010 2400 132 179 1
V40 (526) Hatchback 10/2012-08/2019
Vehicle Engine Fuel Date CC KW CV Traction
T3 1 04/2015-08/2019 1498 112 152 1
T3 1 02/2015-08/2019 1969 112 152 1
T4 1 08/2015-08/2019 1969 140 190 1
T4 1 10/2013-12/2015 1984 132 180 1
T4 GTDi 1 10/2012-12/2016 1596 132 180 1
T5 1 02/2013-12/2015 1984 157 214 1
T5 1 01/2014-12/2015 2497 183 249 1
T5 1 10/2012-12/2016 2497 187 254 1
D2 2 10/2012-12/2016 1560 84 114 1
D2 2 02/2015-08/2019 1969 88 120 1
D3 2 04/2015-08/2019 1969 110 150 1
D3 2 10/2012-03/2015 1984 110 150 1
D4 2 05/2014-08/2019 1969 140 190 1
D4 2 10/2012-12/2014 1984 130 177 1
D4 Polestar 2 05/2014-08/2019 1969 147 200 1
V40 (526) Hatchback Van 09/2013-12/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D2/ DRIVe 2 09/2013-12/2015 1560 84 114 1
2.0 D3 2 09/2013-12/2015 1984 110 150 1
2.0 D4 2 09/2013-12/2014 1984 130 177 1
V50 (545) Estate 12/2003-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.6

B 4164 S3

 1 01/2005-12/2012 1596 74 101 1
1.8

B 4184 S11

 1 04/2004-12/2010 1798 92 125 1
2.0

B 4204 S3

 1 10/2006-12/2012 1999 107 146 1
2.4

B 5244 S5

 1 04/2004-12/2010 2435 103 140 1
2.4

B 5244 S4

 1 04/2004-12/2010 2435 125 170 1
2.4 AWD

B 5244 S4

 1 08/2006-12/2009 2435 125 170 3
T5

B 5254 T3

 1 04/2004-12/2007 2521 162 220 1
T5

B 5254 T7

 1 03/2007-12/2012 2521 169 230 1
T5 AWD

B 5254 T3

 1 04/2004-12/2007 2521 162 220 3
T5 AWD

B 5254 T7

 1 03/2007-12/2010 2521 169 230 3
1.8 Bifuel 18 01/2009-09/2010 1798 93 126 1
1.8 Flexfuel

B 4184 S8

 19 01/2005-12/2010 1798 92 125 1
2.0 FlexFuel

B 4204 S4

 19 01/2010-12/2012 1999 107 146 1
1.6 D

D 4164 T

 2 03/2005-12/2012 1560 80 109 1
1.6 D

D 4164 T

 2 01/2005-12/2011 1560 81 110 1
2.0 CDI

D 4204 T2

 2 12/2003-12/2006 1998 98 133 1
2.0 D

D 4204 T

 2 04/2004-12/2010 1998 100 136 1
2.0 D4

D 4204 T2

 2 07/2005-12/2006 1998 96 131 1
2.4 TDi

D 5244 T9

 2 05/2007-12/2010 2400 120 163 1
D2

D 4162 T

 2 01/2010-12/2012 1560 84 114 1
D3

D 5204 T5

 2 10/2010-12/2012 1984 110 150 1
D4

D 5204 T

 2 10/2010-12/2012 1984 130 177 1
D5

D 5244 T13

D 5244 T8

 2 03/2006-12/2010 2400 132 179 1
VOLVO (CHANGAN)
S40 () Saloon 06/2006-
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 06/2006-12/2011 2435 125 170 1
2.5 1 06/2006-12/2010 2521 162 220 1
Return
