Product 78RBD23558

Description
Brake disc
Axe
Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073153470
QR Code
Url
https://catalogonuevo.rbrake.com/Producto/Details?idProducto=78RBD23558
Weight (gr.)
17172
Measures
Ø330x20x68.8
Brake Disc Type: Vented
Minimum thickness [mm]: 18.4
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 120
Wheel Hub Diameter [mm]: 75
Reference applications
Brand OE Reference
BMW 3421 6 775 287
Maker Cross reference
ATE 24.0120-0229.2
ATE 420229
BREMBO 09.C411.13
DELPHI LOCKHEED BG4664BC
DELPHI LOCKHEED BG9421BC
FERODO DDF2504VC
GIRLING 6066175
HELLA-PAGID 8DD 355 132-851
LETEC LBB058V
ROAD HOUSE 61550.10
SANLI SL36975
TEXTAR 92265925
BMW
5 Serie VI (F10) Saloon 01/2009-10/2016
Vehicle Engine Fuel Date CC KW CV Traction
520 i

N20 B16 A

 1 07/2013-10/2016 1592 125 170 2
520 i

N20 B20 A

N20 B20 B

 1 09/2011-10/2016 1997 120 163 2
520 i

N20 B20 A

N20 B20 B

 1 09/2011-10/2016 1997 135 184 2
523 i

N52 B25 A

N52 B25 AF

N52 B25 B

N52 B25 BF

 1 01/2010-08/2011 2497 150 204 2
523 i

N53 B30 A

 1 06/2009-08/2011 2996 150 204 2
523 i

N53 B30 A

 1 01/2010-08/2011 2996 155 211 2
528 i xDrive

N20 B20 A

 1 09/2011-10/2016 1997 180 245 3
528i

N20 B20 A

 1 10/2014-10/2016 1997 160 218 2
528i

N20 B20 A

 1 09/2011-10/2016 1997 180 245 2
528i

N52 B30 A

 1 10/2009-08/2011 2996 179 243 2
528i

N53 B30 A

 1 03/2010-08/2011 2996 190 258 2
530i

N52 B30 A

N52 B30 AF

N52 B30 BF

 1 03/2010-06/2013 2996 190 258 2
530i

N53 B30 A

 1 05/2011-06/2013 2996 200 272 2
535 i xDrive

N55 B30 A

 1 03/2011-10/2016 2979 225 306 3
535 i xDrive

N55 B30 A

 1 07/2013-10/2016 2979 240 326 3
535i

N55 B30 A

 1 01/2009-10/2016 2979 224 305 2
535i

N55 B30 A

 1 01/2010-10/2016 2979 225 306 2
535i

N55 B30 A

 1 07/2013-10/2016 2979 240 326 2
ActiveHybrid

N55 B30 A

 13 12/2011-10/2016 2979 225 306 2
ActiveHybrid

N55 B30 A

 13 12/2011-10/2016 2979 250 340 2
518 d

N47 D20 C

 2 07/2013-10/2016 1995 100 136 2
518 d

N47 D20 C

 2 07/2013-06/2014 1995 105 143 2
518 d

B47 D20 A

 2 07/2014-10/2016 1995 110 150 2
518 d

B47 D20 A

 2 10/2013-10/2016 1995 120 163 2
520 d

N47 D20 C

 2 01/2013-06/2014 1995 100 136 2
520 d

B47 D20 A

N47 D20 C

 2 06/2010-10/2016 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 135 184 2
520 d

B47 D20 A

 2 07/2014-10/2016 1995 140 190 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 147 200 2
520 d

B47 D20 A

 2 07/2014-10/2016 1995 151 205 2
520 d

B47 D20 A

 2 10/2013-10/2016 1995 155 211 2
520 d xDrive

N47 D20 C

 2 01/2013-06/2014 1995 100 136 3
520 d xDrive

B47 D20 A

 2 07/2013-10/2016 1995 120 163 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 135 184 3
520 d xDrive

B47 D20 A

 2 07/2014-10/2016 1995 140 190 3
520 d xDrive

N47 D20 C

 2 01/2013-06/2014 1995 147 200 3
520 d xDrive

B47 D20 A

 2 07/2014-10/2016 1995 151 205 3
520 d xDrive

B47 D20 A

 2 10/2013-10/2016 1995 155 211 3
525 d

N47 D20 D

 2 09/2011-10/2016 1995 155 211 2
525 d

N47 D20 D

 2 09/2011-10/2016 1995 160 218 2
525 d

N57 D30 A

 2 03/2010-08/2011 2993 150 204 2
525 d xDrive

N47 D20 D

 2 09/2011-10/2016 1995 155 211 3
525 d xDrive

N47 D20 D

 2 09/2011-10/2016 1995 160 218 3
530 d

N57 D30 A

 2 01/2010-08/2011 2993 180 245 2
530 d

N57 D30 A

 2 09/2011-10/2016 2993 190 258 2
530 d

N57 D30 A

 2 09/2010-10/2016 2993 210 286 2
530 d xDrive

N57 D30 A

 2 03/2011-10/2016 2993 190 258 3
530 d xDrive

N57 D30 A

 2 03/2011-10/2016 2993 210 286 3
5 Serie VI Touring (F11) Estate 11/2009-
Vehicle Engine Fuel Date CC KW CV Traction
520 i

N20 B20 A

N20 B20 B

 1 09/2011-02/2017 1997 120 163 2
520 i

N20 B20 A

N20 B20 B

 1 10/2010-02/2017 1997 135 184 2
523 i

N52 B25 A

N52 B25 AF

N52 B25 B

 1 11/2009-08/2011 2497 150 204 2
523 i

N53 B30 A

 1 11/2009-08/2011 2996 150 204 2
528 i xDrive

N20 B20 A

 1 09/2011-02/2017 1997 180 245 3
528i

N20 B20 A

 1 09/2011-02/2017 1997 180 245 2
528i

N53 B30 A

 1 11/2009-08/2011 2996 190 258 2
530i

N52 B30 A

N52 B30 AF

 1 03/2010-05/2013 2996 190 258 2
530i

N53 B30 A

 1 07/2011-06/2013 2996 200 272 2
535 i xDrive

N55 B30 A

 1 09/2011-02/2017 2979 225 306 3
535i

N55 B30 A

 1 06/2010-02/2017 2979 225 306 2
518 d

B47 D20 A

N47 D20 C

 2 07/2013-02/2017 1995 100 136 2
518 d

N47 D20 C

 2 07/2013-06/2014 1995 105 143 2
518 d

B47 D20 A

 2 07/2014-02/2017 1995 110 150 2
518 d

B47 D20 A

 2 07/2014-02/2017 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 100 136 2
520 d

B47 D20 A

N47 D20 C

 2 06/2010-02/2017 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 135 184 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 140 190 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 147 200 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 151 205 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 155 211 2
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 100 136 3
520 d xDrive

B47 D20 A

 2 07/2013-02/2017 1995 120 163 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 135 184 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 140 190 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 147 200 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 151 205 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 155 211 3
525 d

N47 D20 D

 2 09/2011-02/2017 1995 155 211 2
525 d

N47 D20 D

 2 09/2011-02/2017 1995 160 218 2
525 d

N57 D30 A

 2 09/2010-08/2011 2993 150 204 2
525 d xDrive

N47 D20 D

 2 07/2013-02/2017 1995 155 211 3
525 d xDrive

N47 D20 D

 2 07/2013-02/2017 1995 160 218 3
530 d

N57 D30 A

 2 06/2010-08/2011 2993 180 245 2
530 d

N57 D30 A

 2 09/2011-02/2017 2993 190 258 2
530 d

N57 D30 A

 2 09/2011-02/2017 2993 210 286 2
530 d xDrive

N57 D30 A

 2 03/2011-02/2017 2993 190 258 3
530 d xDrive

N57 D30 A

 2 03/2011-02/2017 2993 210 286 3
BMW (BRILLIANCE)
5 SERIES VI (F10, F18) Saloon 08/2010-
Vehicle Engine Fuel Date CC KW CV Traction
2.5 520Li 1 12/2010- 2497 130 177 1
2.5 523Li 1 08/2010- 2497 150 204 1
3.0 528Li 1 08/2010- 2996 190 258 1
3.0 535Li 1 08/2010- 2979 225 306 1
520 Li

N20 B20 D

 1 09/2013-05/2017 1997 135 184 2
525 Li

N20 B20 A,N20 B20 C

 1 08/2012-05/2017 1997 160 218 2
528 Li 1 05/2014- 1997 180 245 1
528 Li xDrive

N20 B20 C

 1 05/2014-05/2017 1997 180 245 3
530 Li 1 11/2011-05/2014 2996 190 258 1
530 Le Hybrid

N20 B20 C

 13 01/2015-05/2017 1997 160 218 2
