Product 78RBD23300

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073153166
QR Code
Url
https://catalogonuevo.rbrake.com/Producto/Details?idProducto=78RBD23300
Weight (gr.)
7048
R90 Homologation
R90 90R-02C0415/0038
Measures
Ø239x12x35.5
Brake Disc Type: solid
Minimum thickness [mm]: 10
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 65
Reference applications
Brand OE Reference
VW 171 6153 01
VW 175 615 301
VW 321 615 301
VW 839 615 301
Maker Cross reference
ATE 24.0112-0106.1
BENDIX ANTIGUO 561141B
BOSCH 0 986 478 011
BREMBO 08.4177.10
DELPHI LOCKHEED BG2116
LETEC LBA003S
NECTO WN283
ROAD HOUSE 6088.01
SANLI SL10475
TRW DF1516
AUDI
50 (863) Hatchback 08/1974-07/1978
Vehicle Engine Fuel Date CC KW CV Traction
0.8

HE

 1 01/1976-07/1978 771 25 34 1
1.1

HB

 1 08/1974-07/1978 1093 37 50 1
1.1

HC

 1 08/1974-07/1977 1093 44 60 1
1.3

HJ

 1 01/1977-07/1978 1272 43 58 1
1.3

HH

 1 08/1977-07/1978 1272 44 60 1
80 II B1 / FOX (80, 82) Saloon 05/1972-07/1978
Vehicle Engine Fuel Date CC KW CV Traction
1.5

YJ

ZB

 1 05/1972-08/1975 1471 55 75 1
1.5

ZC

 1 05/1972-07/1976 1471 63 85 1
1.6

YN

 1 09/1975-07/1978 1588 55 75 1
1.6

YP

 1 09/1975-07/1978 1588 63 85 1
1.6 GT

XX

 1 09/1973-07/1976 1584 74 100 1
1.6 GTE

YS

 1 01/1976-07/1978 1588 81 110 1
80 III B2 / 4000 (811, 813, 814, 819, 853) Saloon 08/1978-03/1987
Vehicle Engine Fuel Date CC KW CV Traction
1.6

YT

YY

 1 08/1978-07/1981 1588 51 70 1
1.6

WV

WY

YN

 1 08/1978-07/1986 1588 55 75 1
1.6

YP

 1 08/1978-02/1983 1588 63 85 1
1.6

SA

 1 02/1986-07/1986 1595 54 73 1
1.6

DT

JU

 1 08/1978-03/1987 1595 55 75 1
1.6 GLE

YZ

 1 08/1978-07/1982 1588 81 110 1
1.8

SF

 1 02/1986-07/1986 1781 65 88 1
1.8

DS

JV

 1 01/1983-08/1986 1781 66 90 1
1.9 CD-5S

WN

 1 09/1981-07/1983 1921 85 115 1
2.0

HP

JS

 1 10/1983-09/1984 1994 85 115 1
2.2

WE

 1 10/1980-07/1983 2144 85 115 1
1.6 D

CR

JK

 2 08/1980-08/1986 1588 40 54 1
1.6 TD

CY

 2 08/1981-05/1986 1588 51 70 1
90 B2 (813, 814, 853) Saloon 08/1984-07/1988
Vehicle Engine Fuel Date CC KW CV Traction
1.6 TD

CY

 2 10/1985-01/1987 1588 51 70 1
COUPE B2 (81, 855, 856) Coupe 07/1980-10/1988
Vehicle Engine Fuel Date CC KW CV Traction
1.6

YN

 1 07/1980-08/1981 1588 55 75 1
1.8

DD

 1 08/1981-07/1983 1781 55 75 1
1.9

WN

 1 08/1980-07/1983 1921 85 115 1
2.0

HP

JS

 1 09/1983-07/1986 1994 85 115 1
2.2 GT

KX

 1 07/1981-10/1987 2226 85 115 1
SEAT
CORDOBA (6K1, 6K2) Saloon 02/1993-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.0 CL 1 02/1993-06/1996 1043 33 45 1
1.0 i

AER

ALD

ANV

AUC

 1 09/1996-10/2002 999 37 50 1
1.4 i

ABD

AEX

AKK

AKV

ANW

APQ

AUD

 1 06/1994-10/2002 1389 44 60 1
1.6 i

1F

 1 05/1994-06/1999 1595 55 75 1
1.6 i

ABU

AEE

ALM

 1 02/1993-10/2002 1598 55 75 1
1.8 i

ABS

ACC

ADZ

 1 02/1993-09/2002 1781 66 90 1
1.7 SDI 2 07/1997-06/1999 1716 44 60 2
1.9 D

1Y

 2 01/1996-08/1996 1896 47 64 1
1.9 D

1Y

 2 02/1993-08/1996 1896 50 68 1
1.9 SDI

AEY

 2 08/1996-06/1999 1896 47 64 1
1.9 TD

AAZ

 2 02/1993-08/1996 1896 55 75 1
1.9 TDI

1Z

AGR

AHU

ALH

 2 08/1996-10/2002 1896 66 90 1
CORDOBA Vario (6K5) Estate 07/1996-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 12/1997-04/1999 1390 40 54 1
1.4 i

AEX

AKK

AKV

ANW

APQ

AUD

 1 09/1996-12/2002 1389 44 60 1
1.7 SDI 2 07/1997-06/1999 1716 44 60 2
1.9 SDI

AEY

 2 09/1996-06/1999 1896 47 64 1
1.9 SDI

AGP

AQM

 2 06/1999-12/2002 1896 50 68 1
CORDOBA II (6K2) Saloon 06/1999-10/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 06/1999-10/2002 1390 44 60 1
1.6 1 06/1999-10/2002 1598 55 75 1
CORDOBA II Vario (6K5) Estate 06/1999-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 06/1999-12/2002 1390 44 60 1
IBIZA II (6K1) Hatchback 03/1993-05/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i

ABD

AEX

AKK

AKV

ANW

APQ

AUD

 1 09/1993-02/2002 1389 44 60 1
1.6 i

1F

 1 09/1994-06/1999 1595 55 75 1
1.6 i

ABU

AEE

ALM

 1 03/1993-02/2002 1598 55 75 1
1.8 i

ABS

ACC

ADZ

 1 03/1993-08/1999 1781 66 90 1
1.9 D

1Y

 2 04/1993-06/1999 1896 47 64 1
1.9 D 2 10/1994-08/1996 1896 50 68 1
1.9 SDI

AEY

 2 08/1996-08/1999 1896 47 64 1
1.9 TD

AAZ

 2 03/1993-08/1996 1896 55 75 1
1.9 TDI

1Z

AGR

AHU

ALH

 2 08/1996-02/2002 1896 66 90 1
1.9 TDI

AFN

ASV

 2 02/1997-02/2002 1896 81 110 1
TOLEDO (1L2) Hatchback 01/1991-10/1999
Vehicle Engine Fuel Date CC KW CV Traction
1.6 i

1F

 1 05/1991-12/1993 1595 52 71 1
1.6 i

ABN

EZ

 1 05/1991-03/1999 1595 54 73 1
1.6 i

1F

 1 01/1993-03/1999 1595 55 75 1
1.8 i

RP

 1 05/1991-12/1996 1781 65 88 1
1.8 i

ABS

ACC

ADZ

 1 11/1993-12/1996 1781 66 90 1
1.9 D

1Y

 2 12/1995-03/1999 1896 47 64 1
1.9 D

1Y

 2 05/1991-03/1999 1896 50 68 1
1.9 TD

AAZ

 2 05/1991-03/1999 1896 55 75 1
VW
CADDY / RABBIT PICKUP (14) Pickup 08/1979-11/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.5

JB

 1 08/1982-07/1983 1457 51 70 1
1.6

EM

 1 10/1982-10/1983 1588 55 75 1
1.6

EW

 1 01/1983-07/1992 1595 55 75 1
1.8

JH

 1 08/1985-07/1992 1781 70 95 1
1.6 D

CR

JK

ME

 2 08/1982-07/1992 1588 40 55 1
GOLF I / RABBIT (17) Hatchback 04/1974-12/1985
Vehicle Engine Fuel Date CC KW CV Traction
1.1

FA

GG

 1 04/1974-07/1983 1093 37 50 1
1.5

JB

 1 08/1977-07/1983 1457 51 70 1
1.5

FH

 1 04/1974-12/1975 1471 51 70 1
1.6

FT

 1 08/1975-07/1977 1588 51 70 1
1.6

EM

FN

FP

 1 08/1975-02/1984 1588 55 75 1
1.6

EW

HN

 1 01/1983-02/1984 1595 55 75 1
GOLF I / RABBIT (155) Convertible 01/1979-08/1993
Vehicle Engine Fuel Date CC KW CV Traction
1.5

JB

 1 01/1979-11/1983 1457 51 70 1
1.6

EM

 1 08/1979-07/1983 1588 55 75 1
1.6 1 08/1983-07/1987 1595 51 69 1
1.6

RE

 1 04/1986-02/1990 1595 53 72 1
1.6

EW

HN

 1 08/1983-04/1992 1595 55 75 1
GOLF II (19E, 1G1) Hatchback 08/1983-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.3

GT

 1 08/1983-10/1986 1272 43 58 1
1.3 Cat

2G

MH

NZ

 1 06/1986-12/1992 1272 40 55 1
1.6

PN

 1 10/1986-12/1992 1595 51 70 1
1.6

EZA

PN

 1 08/1986-07/1991 1595 51 69 1
1.6

RF

 1 02/1986-10/1991 1595 53 72 1
1.6

ABN

EZ

HM

 1 08/1983-07/1992 1595 55 75 1
1.8 1 10/1989-07/1992 1781 51 69 1
1.8

GU

GX

HV

 1 08/1984-10/1991 1781 66 90 1
1.8 i Cat

GX

RP

 1 08/1987-10/1991 1781 66 90 1
1.8 i Cat Syncro

RP

 1 08/1987-10/1991 1781 66 90 3
1.8 Syncro

GU

GX

 1 02/1986-07/1991 1781 66 90 3
1.8 Syncro

1P

 1 08/1988-07/1991 1781 72 98 3
1.6 D

ME

 2 08/1983-10/1991 1588 37 50 1
1.6 D

JP

ME

 2 08/1983-10/1991 1588 40 54 1
1.6 TD

1V

 2 08/1989-10/1991 1588 44 60 1
1.6 TD

JR

MF

 2 08/1983-10/1991 1588 51 70 1
1.6 TD 2 08/1983-07/1985 1588 55 75 2
1.6 TD

RA

SB

 2 04/1989-10/1991 1588 59 80 1
GOLF II Furgoneta (19E, 1G1) Hatchback Van 08/1983-07/1991
Vehicle Engine Fuel Date CC KW CV Traction
1.8 i

RP

 1 08/1987-07/1991 1781 66 90 1
1.6 2 08/1989-07/1991 1588 44 60 1
1.6 D

JP

 2 08/1983-07/1991 1588 40 54 1
GOLF III (1H1) Hatchback 10/1989-11/2000
Vehicle Engine Fuel Date CC KW CV Traction
1.0 1 10/1994-09/1996 997 37 50 1
1.3 1 08/1991-07/1992 1272 40 54 1
1.4

ABD

AEX

 1 11/1991-08/1997 1390 40 55 1
1.4

ABD

AEX

 1 10/1991-08/1997 1390 44 60 1
1.6

ABU

AEA

AEE

 1 09/1992-08/1997 1598 55 75 1
1.8

AAM

 1 11/1991-08/1997 1781 55 75 1
1.8

ABS

ACC

ADD

ADZ

 1 11/1991-08/1997 1781 66 90 1
1.8 Syncro (1HX1)

ABS

ADZ

 1 01/1993-08/1997 1781 66 90 3
1.9 D

1Y

 2 11/1991-08/1997 1896 47 64 1
1.9 SDI

AEY

 2 07/1995-08/1997 1896 47 64 1
1.9 TD, GTD

AAZ

 2 11/1991-08/1997 1896 55 75 1
GOLF III Van (1H1) Hatchback Van 08/1991-12/1997
Vehicle Engine Fuel Date CC KW CV Traction
1.4

ABD

AEX

 1 08/1991-05/1996 1390 44 60 1
1.6 1 08/1992-09/1997 1598 55 75 1
1.8

AAM

 1 08/1991-07/1995 1781 55 75 1
1.8

ABS

ADZ

 1 08/1991-12/1997 1781 66 90 1
1.9 D 2 08/1991-07/1995 1896 55 75 1
1.9 SDI

AEY

 2 08/1995-09/1997 1896 47 64 1
GOLF III Van (1H5) Estate Van 08/1991-12/1999
Vehicle Engine Fuel Date CC KW CV Traction
1.4

ABD

AEX

 1 05/1993-07/1995 1390 44 60 1
GOLF III Variant (1H5) Estate 07/1993-04/1999
Vehicle Engine Fuel Date CC KW CV Traction
1.4

ABD

 1 07/1993-04/1999 1390 40 55 1
1.4

ABD

AEX

APQ

 1 07/1993-04/1999 1390 44 60 1
1.6

AEK

AFT

AKS

 1 07/1994-04/1999 1595 74 101 1
1.8 Syncro

ADZ

 1 10/1994-04/1999 1781 66 90 3
JETTA I / ATLANTIC (16) Saloon 08/1978-12/1987
Vehicle Engine Fuel Date CC KW CV Traction
1.5

JB

 1 08/1978-02/1984 1457 51 70 1
1.6 TD

CY

 2 03/1982-02/1984 1588 51 70 1
JETTA II (19E, 1G2, 165) Saloon 08/1983-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.3

GT

 1 01/1984-10/1986 1272 43 58 1
1.3 Cat

2G

MH

NZ

 1 06/1987-12/1991 1272 40 55 1
1.6

PN

 1 10/1986-10/1991 1595 51 70 1
1.6

RF

 1 03/1986-10/1991 1595 53 72 1
1.6

ABN

EZ

HM

 1 01/1984-07/1992 1595 55 75 1
1.8

RH

 1 08/1986-01/1990 1781 62 84 1
1.8 1 08/1984-07/1988 1781 70 95 1
1.8

HT

RV

 1 01/1985-12/1992 1781 77 105 1
1.8

RD

 1 08/1985-10/1987 1781 79 107 1
1.8

EV

GZ

PB

 1 01/1984-10/1991 1781 82 112 1
1.8 Cat

PF

 1 01/1987-10/1991 1781 79 107 1
1.8 Syncro

RH

 1 08/1987-07/1988 1781 62 84 3
1.8 Syncro

GU

RP

 1 08/1987-12/1988 1781 66 90 3
1.8 Syncro

1P

 1 08/1988-07/1991 1781 72 98 3
1.6 D

JP

ME

 2 01/1984-10/1991 1588 40 54 1
1.6 TD

1V

 2 01/1990-10/1991 1588 44 60 1
1.6 TD

JR

MF

 2 01/1984-10/1991 1588 51 70 1
1.6 TD

RA

SB

 2 04/1989-10/1991 1588 59 80 1
PASSAT B1 / DASHER (32) Hatchback 05/1973-07/1981
Vehicle Engine Fuel Date CC KW CV Traction
1.5

YJ

ZB

 1 07/1973-12/1975 1471 55 75 1
1.5

ZC

 1 05/1973-12/1975 1471 63 86 1
1.6

FS

 1 08/1975-07/1980 1588 53 72 1
1.6

YP

 1 08/1975-07/1980 1588 63 85 1
1.6 GLI

YS

 1 08/1977-07/1980 1588 81 110 1
PASSAT B1 Variant / DASHER (33) Estate 05/1973-10/1981
Vehicle Engine Fuel Date CC KW CV Traction
1.3

FY

 1 05/1973-07/1980 1272 40 55 1
1.3

ZA

 1 05/1973-01/1978 1297 40 55 1
1.3

ZF

 1 10/1973-01/1978 1297 44 60 1
1.5

YJ

ZB

 1 10/1973-08/1975 1471 55 75 1
1.5

ZC

 1 10/1973-12/1975 1471 63 86 1
1.6

YN

 1 02/1976-07/1980 1588 55 75 1
1.6

YP

 1 08/1975-07/1980 1588 63 85 1
1.6 i

YS

 1 06/1978-07/1980 1588 81 110 1
1.5 D

CK

 2 02/1977-07/1980 1471 37 50 1
1.6 D

CR

 2 08/1980-07/1981 1588 40 54 1
PASSAT B2 / CARAT / CORSAR / QUANTUM / SANTANA (32B) Hatchback 09/1979-07/1989
Vehicle Engine Fuel Date CC KW CV Traction
1.3

FY

 1 08/1980-07/1983 1272 40 55 1
1.3

FZ

 1 08/1980-07/1986 1272 44 60 1
1.3

EP

EU

 1 08/1980-07/1986 1297 44 60 1
1.6

WV

WY

YN

 1 09/1979-03/1988 1588 55 75 1
1.6

YP

 1 01/1981-02/1983 1588 63 85 1
1.6

DTA

PP

 1 08/1986-03/1988 1595 51 70 1
1.6

RL

 1 02/1986-03/1988 1595 53 72 1
1.6

DT

 1 08/1980-03/1988 1595 55 75 1
1.8

RM

 1 05/1986-03/1988 1781 64 87 1
1.8

DS

JN

JV

 1 01/1983-03/1988 1781 66 90 1
1.6 D

CR

JK

 2 08/1980-03/1988 1588 40 54 1
1.6 TD

CY

 2 04/1982-03/1988 1588 51 70 1
1.6 TD

RA

 2 08/1988-07/1989 1588 59 80 1
PASSAT B2 Variant / CARAT / CORSAR / QUANTUM (33B) Estate 08/1980-06/1989
Vehicle Engine Fuel Date CC KW CV Traction
1.3

FY

 1 08/1980-07/1983 1272 40 55 1
1.3

FZ

 1 08/1980-07/1986 1272 44 60 1
1.3

EP

EU

 1 08/1980-07/1986 1297 44 60 1
1.6

WV

WY

YN

 1 08/1980-07/1983 1588 55 75 1
1.6

YP

 1 01/1981-02/1983 1588 63 85 1
1.6

DTA

PP

 1 08/1986-03/1988 1595 51 70 1
1.6

RL

 1 02/1986-03/1988 1595 53 72 1
1.6

DT

JU

 1 08/1983-03/1988 1595 55 75 1
1.8

RM

 1 05/1986-03/1988 1781 64 87 1
1.8

DS

JN

JV

 1 01/1983-03/1988 1781 66 90 1
1.8

DZ

 1 12/1983-03/1988 1781 82 112 1
1.6 D

CR

JK

 2 08/1980-03/1988 1588 40 54 1
1.6 TD

CY

 2 04/1982-03/1988 1588 51 70 1
PASSAT B2 / CARAT / CORSAR / SANTANA (32B) Saloon 05/1982-06/1989
Vehicle Engine Fuel Date CC KW CV Traction
1.6

DTA

PP

 1 08/1986-03/1988 1595 51 70 1
1.6

RL

 1 01/1985-03/1988 1595 53 72 1
1.6

DT

JU

 1 08/1984-03/1988 1595 55 75 1
1.8

RM

 1 05/1986-03/1988 1781 64 87 1
1.8

DS

JN

 1 01/1985-03/1988 1781 66 90 1
1.6 D

JK

 2 08/1984-03/1988 1588 40 54 1
1.6 TD

CY

 2 01/1985-03/1988 1588 51 70 1
POLO III CLASSIC / DERBY / FLIGHT (6V2) Saloon 01/1995-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 05/1996-07/2002 1390 62 84 1
1.6 1 05/1996-09/2001 1595 65 88 1
2.0

ADC

 1 08/1999-09/2001 1984 85 116 1
54 1.4

ANX

 1 01/1998-08/1999 1390 40 54 1
60 1.4

AEX

AKK

AKV

ANW

APQ

AUD

 1 12/1995-09/2001 1390 44 60 1
90 1.8

ABS

ADD

ADZ

 1 01/1997-09/2001 1781 66 90 1
1.9 SDI

AEY

 2 06/1996-09/2001 1896 48 65 1
57 1.7 SDI

AKW

 2 07/1997-09/2001 1715 42 57 1
64 1,9 D

1Y

 2 01/1996-10/1996 1896 47 64 1
64 1.9 SDI

AEY

 2 12/1995-08/1999 1896 47 64 1
68 1.9 SDI

AGP

AQM

 2 08/1999-01/2002 1896 50 68 1
90 1.9 TDI

AGR

AHU

ALE

ALH

 2 09/1996-09/2001 1896 66 90 1
SANTANA / QUANTUM (32B) Saloon 08/1981-12/1985
Vehicle Engine Fuel Date CC KW CV Traction
1.3

FZ

 1 08/1981-07/1983 1272 44 60 1
1.3 CX 1 08/1984-12/1985 1296 44 60 1
1.6

WV

 1 08/1981-12/1984 1588 55 75 1
1.6

YP

 1 08/1981-12/1982 1588 63 85 1
1.6

DT

 1 08/1981-12/1984 1595 55 75 1
1.8

DS

 1 01/1983-12/1984 1781 66 90 1
1.6 D

CR

JK

 2 08/1981-12/1984 1588 40 54 1
1.6 TD

CY

 2 12/1981-12/1984 1588 51 70 1
SCIROCCO (53) Coupe 02/1974-07/1980
Vehicle Engine Fuel Date CC KW CV Traction
1.1

FA

 1 04/1974-07/1979 1093 37 50 1
1.3

GF

 1 08/1979-07/1980 1272 44 60 1
1.5

JB

 1 08/1977-07/1980 1457 51 70 1
1.5

FH

 1 02/1974-12/1975 1471 51 70 1
1.5

FC

YJ

ZB

 1 02/1974-08/1975 1471 55 75 1
1.5

FD

 1 02/1974-12/1977 1471 63 86 1
1.6

FT

 1 08/1975-07/1977 1588 51 70 1
1.6

FN

FP

 1 08/1975-07/1979 1588 55 75 1
1.6

FR

 1 08/1975-07/1980 1588 63 85 1
SCIROCCO II (53B) Coupe 08/1980-07/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.3

HK

 1 08/1983-07/1984 1272 40 55 1
1.3

GF

 1 08/1980-12/1983 1272 44 60 1
1.5

JB

 1 08/1980-12/1983 1457 51 70 1
1.6 1 08/1982-07/1983 1588 55 75 1
1.6

FR

 1 08/1980-04/1984 1588 63 85 1
1.6

EWA

 1 08/1983-07/1984 1595 51 70 1
1.6

RE

 1 04/1986-07/1990 1595 53 72 1
1.6

EW

 1 01/1983-12/1989 1595 55 75 1
VENTO / JETTA III (1H2) Saloon 11/1991-11/2000
Vehicle Engine Fuel Date CC KW CV Traction
1.4

ABD

AEX

 1 11/1991-09/1998 1390 40 55 1
1.4

ABD

AEX

 1 11/1991-09/1998 1390 44 60 1
1.6

ABU

AEA

AEE

 1 09/1992-09/1998 1598 55 75 1
1.8

AAM

 1 11/1991-09/1998 1781 55 75 1
1.8

ABS

ACC

ADD

ADZ

 1 11/1991-09/1998 1781 66 90 1
1.9 D

1Y

 2 11/1991-09/1998 1896 48 65 1
1.9 SDI

AEY

 2 04/1997-09/1998 1896 47 64 1
1.9 TD

AAZ

 2 11/1991-09/1998 1896 55 75 1
Return
