Product 78RBD20415 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073150776
Url: https://catalogonuevo.rbrake.com/Producto/Details?idProducto=78RBD20415
Weight (gr.): 16932

R90 Homologation: 90R-02C0538/0082
Measures: Ø300x28x58.5
: Brake Disc Type: Vented; Minimum thickness [mm]: 25; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 67

Reference applications

Brand	OE Reference
MERCEDES-BENZ	447 421 05 12
MERCEDES-BENZ	639 421 00 12
MERCEDES-BENZ	639 421 02 12
MERCEDES-BENZ	639 421 03 12

Maker	Cross reference
ATE	24.0128-0145.1
ATE	428145
BENDIX ANTIGUO	562322B
BENDIX ANTIGUO	562392B
BOSCH	0 986 479 137
BREMBO	09.8404.10
DELPHI LOCKHEED	BG3838
FERODO	DDF1203
GIRLING	6043731
HELLA-PAGID	54234
LETEC	LBM021V
MINTEX	MDC1728
NECTO	WN1224
ROAD HOUSE	6679.10
SANLI	SL32868
TEXTAR	93123400
TRW	DF4373
VALEO	186890

MERCEDES-BENZ

MARCO POLO Camper (W447) Bus 03/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
200 CDI (447.703, 447.813)	OM 654.920	2	03/2019-	1950	100	136	2
200 CDI (447.703, 447.813)	OM 651.950	2	03/2015-	2143	100	136	2
200 CDI 4-matic (447.703, 447.813)	OM 654.920	2	03/2019-	1950	100	136	3
200 CDI 4-matic (447.703, 447.813)	OM 651.950	2	03/2015-	2143	100	136	3
220 CDI (447.703, 447.813)	OM 654.920	2	03/2019-	1950	120	163	2
220 CDI (447.703, 447.813)	OM 651.950	2	03/2015-	2143	120	163	2
220 CDI 4-matic (447.703, 447.813)	OM 654.920	2	03/2019-	1950	120	163	3
220 CDI 4-matic (447.703, 447.813)	OM 651.950	2	03/2015-	2143	120	163	3
250 CDI (447.703, 447.813)	OM 654.920	2	03/2019-	1950	140	190	2
250 CDI (447.703, 447.813)	OM 651.950	2	03/2015-	2143	140	190	2
250 CDI 4-matic (447.703, 447.813)	OM 654.920	2	03/2019-	1950	140	190	3
250 CDI 4-matic (447.703, 447.813)	OM 651.950	2	03/2015-	2143	140	190	3
300 CDI (447.813, 447.703)	15E4E	2	01/2021-	1950	174	237	2
300 CDI (447.813, 447.703)	OM 654.920	2	03/2019-12/2020	1950	176	239	2
300 CDI 4-matic (447.813, 447.703)		2	01/2021-	1950	174	237	3
300 CDI 4-matic (447.813, 447.703)	OM 654.920	2	03/2019-12/2020	1950	176	239	3

V-Class III (W447) Bus 03/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
V 250 (447.813, 447.815)	M 274.920	1	03/2014-	1991	155	211	2
V 200 CDI / d (447.811, 447.813, 447.815)	OM 651.950	2	03/2014-	2143	100	136	2
V 200 CDI / d 4-matic (447.811, 447.813, 447.815)	OM 651.950	2	04/2015-	2143	100	136	3
V 220 CDI / d (447.811, 447.813, 447.815)	OM 654.920	2	03/2019-	1950	120	163	2
V 220 CDI / d (447.811, 447.813, 447.815)	OM 651.950	2	03/2014-	2143	120	163	2
V 220 CDI / d 4-matic (447.811, 447.813, 447.815)	OM 654.920	2	03/2019-	1950	120	163	3
V 220 CDI / d 4-matic (447.811, 447.813, 447.815)	OM 651.950	2	03/2015-	2143	120	163	3
V 250 BlueTEC / d (447.811, 447.813, 447.815)	OM 651.950	2	03/2014-	2143	140	190	2
V 250 BlueTEC / d 4-matic (447.811, 447.813, 447.815)	OM 651.950	2	12/2014-	2143	140	190	3
V 250 CDI / d (447.811, 447.813, 447.815)	OM 654.920	2	03/2019-	1950	140	190	2
V 250 CDI / d 4-matic (447.811, 447.813)	OM 654.920	2	03/2019-	1950	140	190	3
V 300 CDI / d (447.811, 447.813, 447.815)		2	01/2021-	1950	174	237	2
V 300 CDI / d (447.811, 447.813, 447.815)	OM 654.920	2	03/2019-12/2020	1950	176	239	2
V 300 CDI / d 4-matic (447.811, 447.813)		2	01/2021-	1950	174	237	3
V 300 CDI / d 4-matic (447.811, 447.813)	OM 654.920	2	03/2019-12/2020	1950	176	239	3

VIANO II (W639) Bus 09/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.2 (639.711, 639.811, 639.813)	M 112.951	1	09/2003-	3199	140	190	2
3.2 (639.713, 639.813, 639.815)	M 112.951	1	09/2003-	3199	160	218	2
3.5 (639.811, 639.813, 639.815)	M 272.978	1	09/2007-	3498	190	258	2
3.7 (639.811, 639.813, 639.815)	M 112.976	1	06/2004-07/2007	3724	165	224	2
3.7 (639.815)	M 112.976	1	06/2004-	3724	170	231	2
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)		2	09/2010-	2143	70	95	2
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.982	2	09/2003-	2148	80	109	2
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.982	2	08/2005-	2148	85	116	2
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.980 OM 646.982	2	09/2003-	2148	110	150	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	07/2010-	2143	100	136	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	01/2014-	2143	110	150	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	07/2010-	2143	120	163	2
CDI 2.2 4-matic (639.713)	OM 646.982	2	07/2005-	2148	80	109	3
CDI 2.2 4-matic (639.713)	OM 646.982	2	03/2006-	2148	85	116	3
CDI 2.2 4-matic (639.713)	OM 646.982	2	07/2005-	2148	110	150	3
CDI 2.2 4-matic (639.811, 639.813, 639.815, 639.711,...	OM 651.940	2	07/2010-	2143	100	136	3
CDI 2.2 4-matic (639.811, 639.813, 639.815, 639.711,...	OM 651.940	2	07/2010-	2143	120	163	3
CDI 3.0 (639.811, 639.813, 639.815)	OM 642.990	2	02/2006-	2987	150	204	2
CDI 3.0 (639.811, 639.813, 639.815)	OM 642.890	2	07/2010-	2987	165	224	2

VITO II / MIXTO (W639) Van 08/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
119 (639.601, 639.603, 639.605)	M 112.951	1	09/2003-07/2008	3199	140	190	2
122 (639.601, 639.603, 639.605)	M 112.951	1	09/2003-09/2004	3199	160	218	2
123 (639.601, 639.603, 639.605)	M 112.976	1	06/2004-07/2008	3724	165	224	2
123 (639.601)	M 112.976	1	06/2004-07/2008	3724	170	231	2
126 (639.601, 639.603, 639.605)	M 272.978	1	09/2007-08/2014	3498	190	258	2
109 CDI (639.601, 639.603, 639.605)	OM 646.983	2	09/2003-07/2006	2148	65	88	2
109 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.981	2	08/2006-08/2014	2148	70	95	2
110 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-08/2014	2143	70	95	2
111 CDI (639.601, 639.603, 639.605)		2	05/2012-02/2015	2143	85	116	2
111 CDI (639.601, 639.603, 639.605)	OM 646.982	2	09/2003-08/2007	2148	80	109	2
111 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.982	2	09/2007-08/2014	2148	85	116	2
111 CDI 4x4 (639.601, 639.603, 639.605)	OM 646.982	2	09/2007-08/2014	2148	80	109	3
113 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-08/2014	2143	100	136	2
113 CDI 4x4 (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-08/2014	2143	100	136	3
115 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.982	2	09/2003-08/2014	2148	110	150	2
115 CDI (639.605, 639.601, 639.603)	OM 651.940	2	05/2012-02/2015	2143	110	150	2
115 CDI 4x4 (639.601, 639.603, 639.605)	OM 646.982	2	07/2006-08/2014	2148	110	150	3
116 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-08/2014	2143	120	163	2
116 CDI 4x4 (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-08/2014	2143	120	163	3
120 CDI (639.601, 639.603, 639.605)	OM 642.990	2	03/2006-08/2014	2987	150	204	2
122 CDI (639.601, 639.603, 639.605)	OM 642.890	2	09/2010-08/2014	2987	165	224	2
E-CELL (639.601, 639.603, 639.605)	EM 780.994	11	01/2011-08/2014		60	82	1

VITO II (W639) Bus 09/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
119 (639.701, 639.703, 639.705)	M 112.951	1	09/2003-	3199	140	190	2
122 (639.701, 639.703, 639.705)	M 112.951	1	09/2003-	3199	160	218	2
123 (639.701, 639.703, 639.705)	M 112.976	1	06/2004-07/2008	3724	165	224	2
123 (639.701)	M 112.976	1	06/2004-07/2008	3724	170	231	2
126 (639.701, 639.703, 639.705)	M 272.978	1	09/2007-	3498	190	258	2
109 CDI (639.701, 639.703, 639.705)	OM 646.983	2	09/2003-	2148	65	88	2
109 CDI (639.701, 639.703, 639.705)	OM 646.980	2	09/2006-	2148	70	95	2
109 CDI 4x4 (639.701)	OM 646.981	2	09/2007-08/2014	2148	70	95	3
110 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	70	95	2
111 CDI (639.701, 639.703, 639.705)	OM 646.982	2	09/2003-	2148	80	109	2
111 CDI (639.701, 639.703, 639.705)	OM 646.980	2	09/2007-	2148	85	116	2
111 CDI 4x4 (639.701, 639.703, 639.705)	OM 646.982	2	09/2007-08/2014	2148	80	109	3
113 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-	2143	100	136	2
113 CDI 4x4 (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	100	136	3
115 CDI (639.701, 639.703, 639.705)		2	05/2012-02/2015	2143	110	150	2
115 CDI (639.701, 639.703, 639.705)	OM 646.980 OM 646.982	2	09/2003-	2148	110	150	2
115 CDI 4x4 (639.701, 639.705)	OM 646.982	2	09/2007-08/2014	2148	110	150	3
116 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-	2143	120	163	2
116 CDI 4x4 (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	120	163	3
120 CDI (639.701, 639.703, 639.705)	OM 642.990	2	07/2006-	2987	150	204	2
122 CDI (639.701, 639.703, 639.705)	OM 642.890	2	09/2010-	2987	165	224	2
E-CELL (639.703)	EM 780.994	11	03/2012-		60	82	1

VITO III (W447) Bus 10/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
119		1	01/2016-	1991	135	184	2
2.0 (447.703, 447.705)	M 274.920	1	01/2016-	1991	155	211	2
119 Flex (447.703)	M 274.920	19	11/2015-	1991	135	184	2
114 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	100	136	2
114 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	100	136	3
116 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	120	163	2
116 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	120	163	3
119 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	140	190	2
119 CDI / 119 BlueTEC 4-matic (447.701, 447.703,...	OM 651.950	2	12/2014-	2143	140	190	3
119 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	140	190	3
124 CDI (447.701, 447.703, 447.705)		2	01/2021-	1950	174	237	2
124 CDI (447.701, 447.703, 447.705)	OM 654.920	2	04/2020-12/2020	1950	176	239	2
124 CDI 4-matic (447.701, 447.703, 447.705)		2	01/2021-	1950	174	237	3
124 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	04/2020-	1950	176	239	3

VITO III (W447) Van 10/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 (447.603, 447.605)	M 274.920	1	09/2015-	1991	155	211	2
110 CDI (447.601, 447.603, 447.605)		2	10/2021-	1950	75	102	2
114 CDI (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	100	136	2
114 CDI 4x4 (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	100	136	3
116 CDI (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	120	163	2
116 CDI 4x4 (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	120	163	3
119 CDI (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	140	190	2
119 CDI 4x4 (447.601, 447.603, 447.605)	OM 654.920	2	04/2020-	1950	140	190	3

VITO III Mixto (Double Cabin) (W447) Van 10/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
110 CDI (447.701, 447.703, 447.705)		2	10/2021-	1950	75	102	2
114 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	100	136	2
114 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	100	136	3
116 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	120	163	2
116 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	120	163	3
119 CDI (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	140	190	2
119 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	03/2019-	1950	140	190	3
124 CDI (447.701, 447.703, 447.705)		2	01/2021-	1950	174	237	2
124 CDI (447.701, 447.703, 447.705)	OM 654.920	2	04/2020-12/2020	1950	176	239	2
124 CDI 4-matic (447.701, 447.703, 447.705)		2	01/2021-	1950	174	237	3
124 CDI 4-matic (447.701, 447.703, 447.705)	OM 654.920	2	04/2020-12/2020	1950	176	239	3

MERCEDES-BENZ (FJDA)

VITO (W636) Bus 01/2010-03/2016

Vehicle	Fuel	Date	CC	KW	CV	Traction
119 2.5 (636.705)	1	01/2010-03/2016	2496	140	190	2
122 3.0 (636.705)	1	05/2013-03/2016	2996	165	224	2
115 CDI 2.2 (636.705)	2	01/2010-12/2011	2148	110	150	2
2.1 (636.705)	2	08/2013-03/2016	2143	110	150	2
