Product 78RBD10181 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 1
Barcode: 8424073150547
Url: https://catalogonuevo.rbrake.com/Producto/Details?idProducto=78RBD10181
Weight (gr.): 6964

R90 Homologation: 90R-02C0538/0105
Measures: Ø276x22x77
: Brake Disc Type: Vented; Minimum thickness [mm]: 19; Hole Arrangement/Number: 7; Bolt Hole Circle Ø [mm]: 130; Wheel Hub Diameter [mm]: 85

Reference applications

Brand	OE Reference
MERCEDES-BENZ	901 421 03 12
MERCEDES-BENZ	902 421 03 12
MERCEDES-BENZ	902 421 04 12
MERCEDES-BENZ	902 421 06 12
MERCEDES-BENZ	902 421 07 12
MERCEDES-BENZ	902 421 09 12
VW	2D0 615 301 A
VW	2D0 615 301 B
VW	2D0 615 301 C
VW	2D0 615 301 D

Maker	Cross reference
ATE	24.0122-0161.1
BENDIX ANTIGUO	562086B
BENDIX ANTIGUO	562120B
BENDIX ANTIGUO	567760B
BOSCH	0 986 478 849
BREMBO	09.7314.10
BREMBO	09.7314.14
BREMBO	09.7314.20
BREMBO	09.7314.24
DELPHI LOCKHEED	BG3236
FERODO	FCR153A
FERODO	FCR228A
GIRLING	6027901
HELLA-PAGID	52143
HELLA-PAGID	54315
LETEC	LBM008V
MINTEX	MDC1037
NECTO	WN933
ROAD HOUSE	6461.00
ROAD HOUSE	6461.10
SANLI	SL31786
TEXTAR	92131500
TRW	DF2790
VALEO	186774

DODGE

SPRINTER 2500 (VA) Van 09/1992-12/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.7 D		2	09/2003-12/2006	2685	115	156	2

MERCEDES-BENZ

SPRINTER 2-Ton. (B901, B902) Bus 01/1995-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
214 (902.071, 902.072, 902.671, 902.672)	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
214 NGT (902.072, 902.671, 902.672)	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
208 CDI (901.671, 902.671, 902.672)	OM 611.987	2	04/2000-05/2006	2148	60	82	2
208 D (901.371, 902.371, 902.372)	OM 601.943	2	02/1995-04/2000	2299	58	79	2
210 D (902.471, 902.472)	OM 602.980	2	03/1997-04/2000	2874	75	102	2
211 CDI (902.671, 902.672)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
212 D (902.471, 902.472)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
213 CDI (902.671, 902.672)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
216 CDI (902.671, 902.672)	OM 612.981	2	04/2000-05/2006	2685	115	156	2

SPRINTER 2-Ton. (B901, B902) Van 01/1995-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
214 (901.061, 901.062, 901.661, 901.662, 902.061,...	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
214 NGT (901.661, 902.061, 902.062, 902.661, 902.662)	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
208 CDI (901.661, 901.662, 902.661, 902.662)	OM 611.987	2	04/2000-05/2006	2148	60	82	2
208 D (901.361, 901.362, 902.361, 902.362)	OM 601.943	2	02/1995-04/2000	2299	58	79	2
208 D (901.361, 901.362, 902.361, 902.362)	OM 601.943	2	10/1996-04/2000	2299	60	82	2
210 D (901.461, 901.462, 902.461, 902.462)	OM 602.980	2	01/1997-04/2000	2874	75	102	2
211 CDI (901.661, 901.662, 902.661, 902.662)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
212 D (901.461, 901.462, 902.461, 902.462)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
213 CDI (901.661, 901.662, 902.661, 902.662)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
216 CDI (902.661, 902.662)	OM 612.981	2	04/2000-05/2006	2685	115	156	2

SPRINTER 2-Ton. (B901, B902) Platform/Chassis 01/1995-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
214 (902.011, 902.012, 902.611, 902.612)	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
214 NGT (902.012, 902.611, 902.612)	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
208 CDI (901.611, 901.612, 901.621, 902.611, 902.612,...	OM 611.987	2	04/2000-05/2006	2148	60	82	2
208 D (901.311, 901.312, 901.321, 902.311, 902.312,...	OM 601.943	2	01/1995-04/2000	2299	58	79	2
208 D (901.311, 901.312, 901.321, 902.311, 902.312,...	OM 601.943	2	09/1996-04/2000	2299	60	82	2
210 D (901.421, 902.412)	OM 602.980	2	01/1997-04/2000	2874	75	102	2
211 CDI (901.621, 902.611, 902.612, 902.621, 902.622)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
212 D (901.421, 902.412)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
213 CDI (901.621, 902.611, 902.612, 902.621, 902.622)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
216 CDI (902.611, 902.612, 902.621, 902.622)	OM 612.981	2	04/2000-05/2006	2685	115	156	2

SPRINTER 3-Ton. (B903) Platform/Chassis 01/1995-05/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
314 (903.011, 903.012, 903.013, 903.022, 903.612,...	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
314 4x4 (903.612, 903.613, 903.622)	M 111.984	1	02/1995-05/2006	2295	105	143	3
314 NGT (903.611, 903.612, 903.613, 903.622, 903.012,...	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
308 CDI (903.611, 903.612, 903.613, 903.621, 903.622,...	OM 611.987	2	04/2000-05/2006	2148	60	82	2
308 D 2.3 (903.311, 903.322)	OM 601.943	2	02/1995-04/2000	2299	58	79	2
308 D 2.3 (903.311, 903.322)	OM 601.943	2	11/1996-04/2000	2299	60	82	2
310 D 2.9 (903.411, 903.412, 903.413, 903.421, 903.422,...	OM 602.980	2	01/1997-04/2000	2874	75	102	2
310 D 2.9 4x4 (903.421, 903.422, 903.423)	OM 602.980	2	01/1997-04/2000	2874	75	102	3
311 CDI (903.611, 903.612, 903.613, 903.621, 903.622,...	OM 611.981	2	04/2000-05/2006	2148	80	109	2
311 CDI 4x4 (903.612, 903.613, 903.622, 903.623)	OM 611.981	2	04/2000-05/2006	2148	80	109	3
312 D 2.9 (903.411, 903.412, 903.421, 903.422, 903.423)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
312 D 2.9 4x4 (903.411)		2	02/1995-04/2000	2874	90	122	3
313 CDI (903.611, 903.612, 903.621, 903.622)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
313 CDI 4x4 (903.612, 903.613, 903.622, 903.623)	OM 611.981	2	04/2000-05/2006	2148	95	129	3
316 CDI (903.611, 903.612, 903.613, 903.621, 903.622,...	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	2
316 CDI 4x4 (903.612, 903.613, 903.622, 903.623)	OM 612.981 OM 647.981	2	08/2002-05/2006	2685	115	156	3
308 E (903.312, 903.322)		11	01/1996-05/2006		40	54	2

SPRINTER 3-Ton. (B903) Van 01/1995-05/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
314 (903.061, 903.062, 903.063, 903.661, 903.662)	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
314 4x4 (903.661, 903.662, 903.663)	M 111.984	1	02/1995-05/2006	2295	105	143	3
314 NGT (903.661, 903.061, 903.062, 903.063, 903.662)	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
2.3 D		2	06/1997-12/1999	2299	58	79	2
308 CDI (903.661, 903.662, 903.663)	OM 611.987	2	04/2000-05/2006	2148	60	82	2
308 D 2.3 (903.361, 903.362, 903.363)	OM 601.943	2	02/1995-04/2000	2299	58	79	2
308 D 2.3 (903.361)	OM 601.943	2	02/1995-04/2000	2299	60	82	2
310 D 2.9 (903.461, 903.462, 903.463)	OM 602.980	2	02/1995-04/2000	2874	75	102	2
310 D 2.9 4x4 (903.461, 903.462)	OM 602.980	2	06/1997-04/2000	2874	75	102	3
311 CDI (903.661, 903.662, 903.663)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
311 CDI 4x4 (903.662, 903.663)	OM 611.981	2	08/2002-05/2006	2148	80	109	3
312 D 2.9 (903.461, 903.462, 903.463)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
312 D 2.9 4x4 (903.461, 903.462)	OM 602.980	2	05/1997-08/2002	2874	90	122	3
313 CDI (903.663, 903.662, 903.661)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
313 CDI 4x4 (903.662, 903.663)	OM 611.981	2	08/2002-05/2006	2148	95	129	3
316 CDI (903.661, 903.662, 903.663)	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	2
316 CDI 4x4 (903.662, 903.663)	OM 612.981 OM 647.981	2	02/2001-05/2006	2685	115	156	3
308 E (903.362)		11	01/1996-05/2006		40	54	2

SPRINTER 3-Ton. (B903) Bus 01/1995-05/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
314 (903.071, 903.072, 903.073, 903.671, 903.672,...	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
314 4x4 (903.672, 903.673)	M 111.984	1	02/1995-05/2006	2295	105	143	3
314 NGT (903.072, 903.671, 903.672)	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
2.3 D		2	06/1997-12/1999	2299	58	79	2
308 CDI (903.671, 903.672, 903.673)	OM 611.987	2	04/2000-05/2006	2148	60	82	2
308 D (903.372, 903.373)	OM 601.943	2	02/1995-04/2000	2299	58	79	2
310 D (903.471, 903.472, 903.473)	OM 602.980	2	01/1997-12/1999	2874	75	102	2
310 D 4x4 (903.472, 903.473)	OM 602.980	2	05/1997-08/2002	2874	75	102	3
311 CDI (903.671, 903.672)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
311 CDI 4x4 (903.672, 903.673)	OM 611.981	2	08/2002-05/2006	2148	80	109	3
312 D 2.9 (903.471, 903.472, 903.473)	OM 602.980	2	02/1995-04/2000	2874	90	122	2
312 D 2.9 4x4 (903.473)	OM 602.980	2	05/1997-08/2002	2874	90	122	3
313 CDI (903.671, 903.672)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
313 CDI 4x4 (903.672, 903.673)	OM 611.981	2	08/2002-05/2006	2148	95	129	3
316 CDI (903.671, 903.672, 903.673)	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	2
316 CDI 4x4 (903.672, 903.673)	OM 612.981 OM 647.981	2	08/2002-05/2006	2685	115	156	3
308 E (903.372)		11	01/1996-05/2006		40	54	2

SPRINTER 4-Ton. (B904) Platform/Chassis 02/1995-05/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
414 (904.012, 904.013, 904.612, 904.613)	M 111.979 M 111.984	1	02/1995-05/2006	2295	105	143	2
414 4x4 (904.012, 904.013, 904.612, 904.613)	M 111.979 M 111.984	1	05/1997-05/2006	2295	105	143	3
414 NGT	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
2.3 D		2	06/1997-12/1999	2299	58	79	2
408 CDI	OM 611.987	2	04/2000-05/2006	2148	60	82	2
408 D	OM 601.943	2	02/1996-05/2006	2299	58	79	2
410 D	OM 602.980	2	02/1996-05/2006	2874	75	102	2
410 D 4x4	OM 602.980	2	05/1997-05/2006	2874	75	102	3
411 CDI	OM 611.981	2	04/2000-05/2006	2148	80	109	2
411 CDI 4x4	OM 611.981	2	04/2000-05/2006	2148	80	109	3
412 D	OM 602.980	2	02/1996-05/2006	2874	85	115	2
412 D	OM 602.980	2	02/1996-05/2006	2874	90	122	2
412 D 4x4	OM 602.980	2	05/1997-05/2006	2874	85	115	3
412 D 4x4	OM 602.980	2	05/1997-05/2006	2874	90	122	3
413 CDI	OM 611.981	2	04/2000-05/2006	2148	95	129	2
413 CDI 4x4	OM 611.981	2	04/2000-05/2006	2148	95	129	3
416 CDI	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	2
416 CDI 4x4	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	3

SPRINTER 4-Ton. (B904) Van 02/1995-05/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
414 (904.062, 904.063, 904.662, 904.663)	M 111.979 M 111.984	1	02/1996-05/2006	2295	105	143	2
414 4x4 (904.062, 904.063, 904.662, 904.663)	M 111.979 M 111.984	1	05/1997-05/2006	2295	105	143	3
414 NGT	M 111.979 M 111.984	16	02/1995-05/2006	2295	95	129	2
2.3 D		2	06/1997-12/1999	2299	58	79	2
408 CDI	OM 611.987	2	04/2000-05/2006	2148	60	82	2
408 D	OM 601.943	2	02/1996-05/2006	2299	58	79	2
410 D	OM 602.980	2	02/1996-05/2006	2874	75	102	2
410 D 4x4	OM 602.980	2	05/1997-05/2006	2874	75	102	3
411 CDI	OM 611.981	2	04/2000-05/2006	2148	80	109	2
411 CDI 4x4	OM 611.981	2	04/2000-05/2006	2148	80	109	3
412 D	OM 602.980	2	02/1996-05/2006	2874	85	115	2
412 D	OM 602.980	2	02/1996-05/2006	2874	90	122	2
412 D 4x4	OM 602.980	2	05/1997-05/2006	2874	85	115	3
412 D 4x4	OM 602.980	2	05/1997-05/2006	2874	90	122	3
413 CDI	OM 611.981	2	04/2000-05/2006	2148	95	129	2
413 CDI 4x4	OM 611.981	2	04/2000-05/2006	2148	95	129	3
414 D 4x4	OM 602.980	2	05/1997-05/2006	2874	90	122	3
416 CDI	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	2
416 CDI 4x4	OM 612.981 OM 647.981	2	04/2000-05/2006	2685	115	156	3

SPRINTER 4-Ton. (B904) Bus 02/1996-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
414 (904.662, 904.663)	M 111.979 M 111.984	1	02/1996-05/2006	2295	105	143	2
408 CDI (904.662, 904.663)	OM 611.987	2	04/2000-05/2006	2148	60	82	2
411 CDI (904.662, 904.663)	OM 611.981	2	04/2000-05/2006	2148	80	109	2
413 CDI (904.663, 904.662)	OM 611.981	2	04/2000-05/2006	2148	95	129	2
416 CDI (904.662, 904.663)	OM 612.981	2	04/2000-05/2006	2685	115	156	2

SPRINTER CLASSIC 3,5-Ton. (B909) Van 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
311 CDI (909.632, 909.633)	OM 646.701	2	09/2013-	2148	80	109	2
313 CDI (909.632, 909.633)	OM 646.701	2	01/2017-	2148	100	136	2

SPRINTER CLASSIC 4,6-Ton. (B909) Bus 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
411 CDI (909.843)	OM 646.701	2	09/2013-	2148	80	109	2

SPRINTER CLASSIC 4,6-Ton. (B909) Van 01/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
413 CDI (909.643)	OM 646.701	2	01/2017-	2148	100	136	2

VW

LT 28-35 (2DB, 2DE, 2DK) Bus 04/1996-07/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3	AGL	1	05/1996-07/2006	2295	105	143	2
2.5 SDI	AGX	2	07/1996-07/2006	2461	55	75	2
2.5 TDI	BBE	2	05/2001-07/2006	2461	61	83	2
2.5 TDI	APA	2	05/1999-07/2006	2461	66	90	2
2.5 TDI	BBF	2	05/2001-07/2006	2461	70	95	2
2.5 TDI	AHD	2	05/1996-08/1999	2461	75	102	2
2.5 TDI	ANJ AVR	2	05/1999-07/2006	2461	80	109	2
2.8 TDI	AGK	2	07/1997-05/2003	2798	92	125	2
2.8 TDI	ATA	2	01/1999-01/2002	2798	96	131	2
2.8 TDI	AUH BCQ	2	05/2001-06/2006	2799	116	158	2

LT 28-46 (2DA, 2DD, 2DH) Van 04/1996-07/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3	AGL	1	05/1996-07/2006	2295	105	143	2
2.5 SDI	AGX	2	09/1996-07/2006	2461	55	75	2
2.5 TDI	BBE	2	05/2001-07/2006	2461	61	83	2
2.5 TDI	APA	2	05/1999-07/2006	2461	66	90	2
2.5 TDI	BBF	2	05/2001-07/2006	2461	70	95	2
2.5 TDI	AHD	2	05/1996-08/1999	2461	75	102	2
2.5 TDI	ANJ AVR	2	05/1999-07/2006	2461	80	109	2
2.8 TDI	AGK	2	07/1997-01/2002	2799	92	125	2
2.8 TDI	ATA	2	01/1999-07/2006	2799	96	130	2
2.8 TDI	AUH BCQ	2	04/2002-07/2006	2799	116	158	2

LT 28-46 (2DC, 2DF, 2DG, 2DL, 2DM) Platform/Chassis 04/1996-07/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3	AGL	1	06/1996-07/2006	2295	105	143	2
2.5 SDI	AGX	2	09/1996-07/2006	2461	55	75	2
2.5 TDI	BBE	2	05/2001-07/2006	2461	61	83	2
2.5 TDI	APA	2	05/1999-07/2006	2461	66	90	2
2.5 TDI	BBF	2	05/2001-07/2006	2461	70	95	2
2.5 TDI	AHD	2	06/1996-08/1999	2461	75	102	2
2.5 TDI	ANJ AVR	2	05/1999-07/2006	2461	80	109	2
2.8 TDI	AGK	2	07/1997-01/2002	2799	92	125	2
2.8 TDI	ATA	2	01/1999-07/2006	2799	96	130	2
2.8 TDI	AUH	2	04/2002-07/2006	2799	116	158	2

Return
